4 Warning and exceptions handling
4.1 System alarm and descriptions
SC1000 supports lots of alarms and protections accordingly during the cutting process, which can
decrease the opportunity of the equipment damaging or people hurting because of user’s improper
operation. User must know all the alarms and the handling ways.
Alarm lists:
Type of alarm
The content of alarm
Trigger condition
Communication alarm
Hardware is not connected,
please check the controller.
The communication between motion
control card and sc10000 is broken
FTC alarm
The communication between motion
control card and FTC is broken
Laser system alarm
The communication between motion
control card and laser is broken
Laser serial communication
alarm
The communication between motion
control card and laser serial port is
broken
X axis related alarm
(Y1/Y2/W axis related
alarm are similar with
X axis.)
Emergency stop alarm
User pressed the button
X axis servo input alarm
X axis servo driver works improperly.
X axis encoder alarm
X axis encoder has no signal
feedback/the feedback signal is in error.
Y1 axis double drive error
Y1 axis double drive error is out of
range.
X axis hardware positive limit
alarm
The machine moves at the X axis
hardware positive limit.
X axis hardware negative
limit alarm
The machine moves at the X axis
hardware negative limit.
X axis software positive limit
alarm
The machine moves at the X axis
software positive limit.
X axis software negative limit
alarm
The machine moves at the X axis
software negative limit alarm.
Z axis hardware up limit
alarm
The cutting head moves at the Z axis
hardware up limit.
