SC1000 Fiber Laser Cutting CNC System User’s Manual Version： V1.00
2017 年 3 月 27 日
Gas type
The type of gas when cutting
Not Use
Gas pressure (Bar)
Gas pressure when cutting
5.00
Start
parameters
Slow start
Start slowly when check.
Start length (mm)
Slow start length.
0.00
Start speed (mm/s)
Slow start speed.
0.00
Follow
parameters
Up Height (mm)
Z axis’s up height after cutting.
20.00
Before laser off delay
(ms)
The delay time after cutting but before laser
off.
0
After laser off delay
(ms)
The delay time after laser off.
0
Drill
parameters
Drill delay (ms)
The delay time after arriving at the drill
location.
1000
Drill power (%)
Laser power when drilling.
50
Drill frequency (Hz)
Laser frequency when drilling.
5000
Drill peak current (%)
The peak current in proportion when drilling.
100
Drill height (mm)
The distance between tips and workpiece
when drilling.
5.00
Gas type
The type of gas when drilling.
Air/o2/Not use
Drill pressure (Bar)
The gas pressure when drilling.
5.00
The descriptions of each special process shows as below:
Special process
Descriptions
Uncut
The selected graphic will be cut after check this option.
Short unlift
When the distance between two cutting point is shorter than the unlifted length
that has been set, the cutting head will not lift once check this option.
Unfollow
The Z axis will not follow when cutting once check this option.
Direct cut
The cutting head will go directly to the following location when start cutting
once check this option.
Section drill
Drilling in two different height.
Gradual drill
The cutting head will go directly to the drilling location and start drilling, and
then go to the following location to cut after finish drilling.
Fix height drill
Drilling in some certain distance between tips and workpiece.
