AUDAC MTX48 - Page 10

10
RJ45 (RS485, Audio, +24V DC):
ForconnectiontoWallPanels
Pin 1 White-Orange  AUDIOWLI&MWX65+
Pin 2 Orange  AUDIOWLI&MWX65-
Pin 3 White-Green  +24VDC
Pin 4 Blue   RS485A
Pin 5 White-Blue  RS485B
Pin 6 Green   GND
Pin 7 White-Brown  AUDIOWMI+
Pin 8 Brown   AUDIOWMI-
RJ45 (RS485, Audio, +24V DC):
ForconnectiontoPagingconsole
Pin 1 White-Orange  Notconnected
Pin 2 Orange  Notconnected
Pin 3 White-Green  +24VDC
Pin 4 Blue   RS485A
Pin 5 White-Blue  RS485B
Pin 6 Green   GND
Pin 7 White-Brown  AUDIOMIC+
Pin 8 Brown   AUDIOMIC-
ATTENTION
Thetwistedpaircablingmustalwaysbe‘straight’.Incaseof
self-madecablingitmustbewiredasdescribedabove,toensure
aproperfunctioningofthesystem.
RS232 (serial connection interface):
Forconnectionwithhomeautomationsystems,orotherremotecontrolequipment
Connection StandardRS232
PIN 2 MTXTX
PIN 3 MTXRX
PIN 5 GND
   Settings
  19200Baud
      8Bit
      1Stopbit
      Noparity
      NoHandshaking

RS232 / RS485 / TCP/IP
TheMTXhasRS232,RS485andTCP/IPportswhichallacceptthesamecommands.The
completecommandsettocontroltheMTXisavailableintheMTXcommandsusermanual
whichisfreelydownloadableonwww.audac.eu
