Peripheral connection limits
ThenumberofperipheraldeviceswhichcanbeconnectedtotheMTXisdependingofthe
currentwhichshouldbedeliveredfromtheMTXside.Everyperipheraldeviceconnected
totheMTXhasacertainpowerconsumptionwhichmustbetakenintoaccount.Thetotal
currentwhichshouldbedeliveredfromtheMTXsidemayneverexceedthe1.5Ampere
limit.Thisincludesthecurrentforallwallpanelinputsforeveryzoneaddedwiththe
currentofthedevicesconnectedtothePAGINGinput.Thetableshownbelowgivesan
overviewofthecurrentconsumptionforeverydevicewhichcanbeconnectedtotheMTX.
Peripheral device Current consumption
WLIWallLineinput
WMIWallMicrophoneinput
MWX43/45Wallpanel
MWX65AllInOneWallpanel
MPX48Pagingconsole
MPX88Pagingconsole
40mA
40mA
14mA
75mA
75mA
75mA
ATTENTION
 Make sure the current consumption of all connected
 peripheral devices added together never exceeds the 1.5
 Amperelimit
