21
3) Connecting wall panels
ConnecttheMWX43/45andMWX65wallpanelstotheWall-Panel(WP)inputs(RJ45
connectors)foreachzone.MultipleMWX43/45wallpanelscanbeconnectedtoone
singleWPinputbyusingbuscabling(connectingallthewallpanelsinparallel).The
assignmentofwhichwallpaneliscontrollingwhichzonecanbedonebysoftware
configuration(Seeconfigurationfunctions).OnlyoneAll-In-OneWallPanelwith
additionalaudioinputcanbeconnectedtooneWPinput.
4) Connecting a computer
AcomputercanbeconnectedtotheMTXthroughEthernet.Ifthecomputerisdirectly
connectedtotheMTX,acrossednetworkcableisnecessary.IftheMTXisconnected
toalocalLANnetwork(connectedtoarouter/switch/hub)astraightnetworkcableis
necessary.AskyourITadministratorforhelp.
Togetaccesstotheuserinterface,enterthefollowingaddressinyourinternetbrowser
addressbar:ī˜Šā€œhttp://192.168.0.192ā€ī˜Š(ThisisthefactorydefaultIPaddressoftheMTX,can
bechangedintheuserinterface).Thedefaultadministratorpassword(givesyouaccess
toallfunctions)isī˜Šā€œMTXā€ī˜Šandthedefaultuserpassword(givesyouonlyaccesstothe
basicfunctions)isī˜Šā€œuserā€.Ifyouwanttomakeanychangestothesettings,youshould
log-inwiththeadministratorpassword.
Configuring the MTX
1) Changing the IP address
YoucanskipthisstepwhenthedefaultIPaddressī˜Šā€œ192.168.0.192ā€ī˜Šisnotusedbyanother
deviceinyournetwork,andisOKforyou.IfyouliketochangetheIPaddress,goto
theī˜Šā€œSetupā€ī˜Šmenu(clicktheiconintheupperrightcornerofthemainscreen)andclick
ā€œNetworkSettingsā€.NowyoucanchangetheIPaddress,andclickī˜Šā€œOKā€ī˜Štoapplythe
changesandsave.Afterwards,yourbrowserwillbeautomaticallyredirectedtothenewIP
addressoftheMTX,andthedefaultIPaddressisnotlongervalid.
2) Changing the password
Youcanskipthisstepifthedefaultpasswordī˜Šā€œMTXā€ī˜Šforadministratorandī˜Šā€œuserā€ī˜Šfor
usersisOKforyou,buywealwaysrecommendtochangethesepasswords,especially
whenyourMTXisconnectedtoapublicnetworkwhereexternalusershaveaccessto.If
youliketochangethepassword,gototheī˜Šā€œSetupā€ī˜Šmenuandclickī˜Šā€œPasswordsettingsā€.
Hereyoucanchangethepasswords.First,theoldpasswordneedstobeentered,and
subsequentlythenewpasswordneedstobeenteredtwice(Max8characters).Pressthe
ā€œOKā€ī˜Šbuttontosavethenewpassword.Now,youalwaysneedtolog-inwiththenew
passwordsandthedefaultpasswordsarenotlongervalid.
3) Configuring wall panels and sources
Gototheī˜Šā€œSetupā€ī˜Šmenuandclickī˜Šā€œSystemconfigurationā€.Nowyouhavethepossibilityto
choosebetweenī˜Šī˜Šī˜Šā€œMWX65ā€ī˜Šandī˜Šā€œMWX43/45ā€.
ToconfigurethesettingsfortheMWX43/45wallpanels,clickthecorrespondingbutton.
Bythedropdownlistthezonecanbechosenforwhichawallpanelshouldbeassigned.
Afterthezoneisselected,clicktheī˜Šā€œSetAddressā€ī˜Šbutton.Thedisplaysonallconnected
wallpanelswillstartblinkingwiththeselectedzonenumber.Pushtheupperbutton
ā€œProgram+ā€ī˜Šonthewallpanelwhichshouldbeassignedwiththatparticularzone.After
theī˜Šā€œProgram+ā€ī˜Šbuttonispressed,thewallpanelwillbelinkedwiththeselectedzone
andthedisplaywillstopblinking.Repeatthisactionforalltheconnectedwallpanelsand
forallzonesuntillazoneisassignedforeveryconnectedwallpanel.
