ToconfigurethesettingsoftheMWX65wallpanels,gobacktothe“Setup”>“System
configuration”menu,andclickthe“MWX65”button.
Afterthisbuttonisclicked,awindowwillbeshownwherealltheconfigurationsettings
fortheMWX65canbemade.Ontheleftside,adropdownlistisshownwherebythe
addressfortheMWX65canbeselected.Theaddresscanbeselectedbetween“W001”
to“W008”.Logicallyitstartswiththeaddress“W001”forthefirstwallpaneland
increasestheaddressforeverysubsequentwallpanel.Afterthedesiredaddressis
selected,clickthe“SetAddress”buttonandthedisplayontheMWX65willstartblinking.
Confirmtheaddressofthewallpanelbypushingthebigrotarybuttononthewallpanel
andtheselectedaddresswillbeassignedtothewallpanel.
Afterthisisdone,thezonewhichshouldbecontrolledbythiswallpanelcanbeselected
bythedropdownlistwhichisshownonepositiontotheright.
Theinputswhichareselectablewiththewallpanelcanbechoseninthe“Selectable
inputs”dropdownlist.Aftertheinputsareclicked,alltheselectedinputswillappearin
thelistboxshownbelow.
CertainactionssuchasVolumeChange,Inputchange,Mute,Tonecontrolandsettings
canbedisabledfromthewallpanelandthephantompoweronthemicrophoneinputcan
beenabledbyclickingthecheckboxes.
Finally,thedisplaybacklightlevelandscreensaversettingscanbeadjusted.
Afterallsettingsaredone,clickthe“SavetoWallpanel”buttonandallyoursettings
willbesendtotheselectedMWX65wallpanel.Repeatthisactionforalltheconnected
MWX65WallPanels.
Ready
Yoursystemisnowcompletelyconfiguredandreadytobeused.
