AUDAC MTX48 - Page 14

14
Input number Corresponding channel
1
2
3
4
5
6
7
8
MicrophoneInput1
MicrophoneInput2
Lineinput3
Lineinput4
Lineinput5
Lineinput6
Line(WLI)+MWX65WallPanelInput
Microphone(WMI)WallPanelInput
Bass and Treble adjustment:
TheBassandTrebleadjustmentcanbedoneonasimilarway.Whenthedesiredfunctionis
selected,thecorrespondingfunctionLEDwillstartblinking.Theadjustmentcanbedonebyrotating
thefunctiondial.Similartothevolumeadjustment,clockwiserotationresultsinalevelincrease
whilecounter-clockwiserotationresultsinaleveldecrease.Whenthelevelissetinneutral
position(0dB),noLED’softhelevel/selectionLED’swillilluminate.Whenanamplification(dB+)
isselected,theupperfourLED’swillilluminatefromoutthecentre,dependingontheselectedlevel.
Whenanattenuationisselected(dB-),thelowerfourLED’swillilluminatefromoutthecentre,
dependingoftheselectedlevel.
POWER
LEVEL
MTX88
ON
PFL
Built-in PFL Loudspeaker and potentiometer:
Thebuilt-inpre-listeningloudspeakermakesitpossibletopre-listeneveryoutputchannelwithout
theneedforanadditionalheadphone.Thechannelwhichiscurrentlyplayingthroughthebuilt-in
pre-listeningloudspeakercanbeselectedbymeansofthePFLselectionswitcheswhicharepro-
videdwitheachzonecontrolsection.ThelevelofthePFLloudspeakercanbecontrolledbyusing
thePFLpotentiometer.

Power switch:
Bymeansofthepowerswitch,thedevicecanbeturnedONandOFF.Whenthedeviceisswitched
on,theblueLEDabovethepowerbuttonwillilluminate.
Powerswitch
Built-inPFL
Loudspeaker
PFLLevel
Potentiometer
