page 9 – 4
D-75 / Sep 2004
TAPE REMOTE MODULE
9
10
11
12
13
22
23
24
25
6
7
8
19
20
21
4
5
16
17
18
1
2
3
14
15
SW1 (RTZ) LED+
SW1 (RTZ) N.O.
SW2 (FF) LED+
SW2 (FF) N.O
SW3 (REW) LED+
SW3 (REW) N.O.
SW4 (STOP) LED+
SW4 (STOP) N.O.
SW5 (REC) LED+
SW5 (REC) N.O.
SW6 (PLAY) LED+
SW6 (PLAY) N.O.
SW1 (RTZ) LED
-
SW1 (RTZ) COMMON
SW2 (FF) LED-
SW2 (FF) COMMON
SW3 (REW) LED-
SW3 (REW) COMMON
SW4 (STOP) LED-
SW4 (STOP) COMMON
SW5 (REC) LED-
SW5 (REC) COMMON
SW6 (PLAY) LED-
SW6 (PLAY) COMMON
N/C
I/O CONTRO
L
PORTS
(DB-25)
TR-75/FF Tape Remote Module
DB Connector Pinouts
SW1
SW2
SW3
SW4
SW5
SW6
