AudioCodes Mediant 800 MSBR Hardware Installation Manual

Hardware Installation Manual 16 Document #: LTRT-10236
Mediant 800 MSBR
Notes:
• The figures above are used only as examples; the number and type of port interfaces
depends on the ordered model.
• For available hardware configurations, please contact your AudioCodes sales
representative.
Table 3-2: Mediant 800B MSBR Front Panel Description
Item # Label Description
1 POWER / STATUS Power and operating status LEDs. For more information, see
Section 3.2.2 on page 19.
2 FXS / FXO / BRI / PRI (Optional) Telephony port interfaces, which can include one
or a combination of the following, depending on ordered
model:
• FXS port interfaces (RJ-11)
• FXO port interfaces (RJ-11)
• ISDN BRI port interfaces (RJ-45)
• ISDN PRI (E1/T1) port interfaces (RJ-48)
Note: The FXS/FXO interfaces support loop-start signalling
(indoor only).
3 GE (Copper GbE) /
V/ADSLoPOTS / DSLoISDN
/ DSLoPOTS /
SHDSL /
GE SFP (Optic Fiber) /
T1E1 (T1 WAN)
(Optional) One or two additional WAN interfaces (copper
GE, SFP, SHDSL, A/VDSL, and E1/T1 WAN). For a list of
supported WAN configurations, please contact your
AudioCodes sales representative.
4 GE 0/0 Gigabit Ethernet (10/100/1000Base-T) copper WAN
interface (RJ-45), provided on all models.
5 GE Up to four Gigabit Ethernet (10/100/1000Base-T) LAN ports
for connecting IP phones, computers, or switches. These
ports support half- and full-duplex modes, auto-negotiation,
and straight or crossover cable detection.
6 FE (Optional) Eight Fast Ethernet (10/100Base-TX) RJ-45 LAN
ports for connecting IP phones, computers, or switches.
These ports support half- and full-duplex modes, auto-
negotiation, and straight or crossover cable detection.
7 // Reset pinhole button for resetting the device and optionally,
for restoring the device to factory defaults.
To restore the device to factory defaults, do the following:
With a paper clip or any other similar pointed object, press
and hold down the pinhole button for at least 12 seconds,
but no longer than 25 seconds.
8 CONSOLE RS-232 serial communication port (RJ-45).
9 USB/WWAN Two USB ports that can be used for various functionalities
such as 3G/4G cellular WAN modem or storage capabilities.

AudioCodes Mediant 800 MSBR Specifications

General

Brand	AudioCodes
Model	Mediant 800 MSBR
Category	Network Router
Language	English
