Service conditions
Indoor and outdoor use permissibleUse
Any positionMounting position
≤ 6,500 ft (2,000 m) above sea level
> 6,500 ft (2,000 m) m above sea level on request
Installation altitude
–40 °F to 140 °F (–40 °C to +60 °C)Standard:Ambient temperature
–40 °F to 158 °F/176 °F (–40 °C to +70 °C/80 °C)
(Class I, Division 1, Groups C and D only)
Options:
For exact version, refer to actuator name tag.
Up to 100 % relative humidity across the entire permissible temperature rangeHumidity
NEMA 4X/6P (IP68)Standard:Enclosure rating to NEMA 250
Enclosure rating 6P fulfils the following requirements:
●
Depth of water: maximum 26 ft (8 m) head of water
●
Duration of continuous immersion in water: Max. 96 hours
●
Up to 10 operations during continuous immersion
Modulating duty is not possible during continuous immersion.
For exact version, refer to actuator name tag.
Pollution degree 4 (when closed), pollution degree 2 (internal)Pollution degree to IEC 60664-1
2 g, from 10 to 200 Hz
Resistant to vibration during start-up or for failures of the plant. However, a fatigue strength may not be
derived from this.Valid for multi-turn actuators in version NORM (with plug & socket connector, without
actuator controls). Not valid in combination with gearboxes.
Vibration resistance to
IEC 60068-2-6
KS: Suitable for use in areas with high salinity, almost permanent condensation, and high
pollution.
Standard:Corrosion protection
KX: Suitable for use in areas with extremely high salinity, permanent condensation, and high
pollution.
Option:
Double layer powder coating
Two-component iron-mica combination
Coating
AUMA silver-gray (similar to RAL 7037)Standard:Color
Available colors on requestOption:
The multi-turn actuators meet or exceed the lifetime requirements of EN 15714-2. Detailed information can
be provided on request.
Lifetime
< 72 dB (A)Noise level
48
SAEx 07.2 – SAEx 16.2 / SAREx 07.2 – SAREx 16.2
Technical data
