AUMA SG 05.1 - Page 57

Danger of corrosion due to damage to paint finish!
→
Touch up damage to paint finish after work on the device.
1. Unfasten motor cover [1].
2. Set required operating time via potentiometer [2].
3. Clean sealing faces of motor cover and housing.
4. Apply a thin film of non-acidic grease (e.g. petroleum jelly) to the sealing faces.
5. Check whether O-ring is in good condition, correctly insert O-ring.
6. Fit motor cover [1] and fasten with screws (tightening torque approx. 50 Nm).
Information: For enclosure protection IP 68, the motor cover is additionally
sealed with thread sealing material.
57
SG 05.1 – SG 12.1/SGR 05.1 – SGR 12.1 Control unit: electronic (MWG)
AC 01.1 Non-Intrusive Modbus RTU Commissioning (basic settings)
