Table 12: Description of the warnings
RemedyDescriptionSignal
No warnings have occurred.
NO WARNINGS
Set the operating time (MONITOR TRIG-
GERS parameter) in accordance with the
actual operating time.
Preset running time for a travel between end
position OPEN and end position CLOSED
has been exceeded.
WARNING OPER. TIME
Check tripping behaviour of end position
switches.
Verify actuator mechanics.
Check modulating behaviour.Preset values for max. starts/h or max. run-
ning time/h have been exceeded.
WARNING STARTS/RUN
Increase dead time.
Reduce number of setpoint changes.
Operate actuator into both end positions
(OPEN and CLOSED).
Position transmitter (potentiometer or RWG)
is not standardised.
INTERNAL FEEDBACK
For further information:
1.
Go to group D0: Press C and hold it
down until diagnostic indication D0 is
displayed.
2.
Go to diagnostic indication D3: Press
3 times.
Internal warnings have occurred.
INTERNAL WARNING
Check position transmitter signal.
1.
Go to group D0: Press C and hold it
down until diagnostic indication D0 is
displayed.
2.
Go to diagnostic indication D7, D8 or
D9: Press either 7, 8 or 9 times.
Signal loss of position transmitter
FEEDBACK E2 LOSS
Check position transmitter wiring.
Check POSITION E2 parameter. The
setting must correspond to the wiring dia-
gram.
Check wiring.Signal loss of setpoint
SETPOINT E1 LOSS
Check wiring.Signal loss of torque source
TORQUE E6 LOSS
Check wiring.Signal loss of the analogue input 1 of the
parallel interface (only for fieldbus/standard
interface combinations)
I/O ANLOG IN1 LOSS
Check wiring.Signal loss of the analogue input 2 of the
parallel interface (only for fieldbus/standard
interface combinations)
I/O ANLOG IN2 LOSS
Check wiring.Signal loss of actual process value E4 (only
if PID controller is available and active)
P-FEEDBACK E4 LOSS
Check wiring.Signal loss of FO cable (for bus with FO loop
topology only)
FIBER OPTIC LOSS
Check wiring.Signal loss of analogue input 1
ANALOG IN1 BUS1 LOSS
Check wiring.Signal loss of analogue input 2
ANALOG IN2 BUS1 LOSS
10.2.4 Status indication S3 - causes for not ready remote
The causes for the NOT READY IND. fault signals (from status indication S0) are
displayed within status indication S3.
NOT READY IND. S3
READY
60
SG 05.1 SG 12.1/SGR 05.1 SGR 12.1 Control unit: electronic (MWG)
Corrective action AC 01.1 Non-Intrusive Modbus RTU
