AUMA SG 05.1 User Manual

FAULT IND. S1
NO FAULT
Table 11: Description of the fault indications
RemedyDescriptionSignal
No fault has occurred.
NO FAULT
For further information:
1.
Go to group D0: Press C and hold it
down until diagnostic indication D0 is
displayed.
2.
Go to diagnostic indication D2: Press
twice.
Internal fault has occurred.
INTERNAL FAULT
Operation command in direction OPEN.Torque fault in direction CLOSE.
TORQUE FAULT (CLOSE)
Set selector switch to position Local control
(LOCAL) and reset fault indication via push
button Reset.
Or:
Perform reset command via fieldbus.
Operation command in direction CLOSE.Torque fault in direction OPEN.
TORQUE FAULT (OPEN)
Set selector switch to position Local control
(LOCAL) and reset fault indication via push
button Reset.
Or:
Perform reset command via fieldbus.
Test/connect phases.One phase is missing.
LOSS OF PHASE
Cool down, wait.Motor protection tripped.
THERMAL FAULT
If the fault indication display persists after
cooling down:
Set selector switch to position Local control
(LOCAL) or reset fault indication via push
button Reset.
Or:
Perform reset command via fieldbus.
Check fuse F4.
For further information:
1.
Go to group D0: Press C and hold it
down until diagnostic indication D0 is
displayed.
2.
Go to diagnostic indication D4: Press
4 x.
The controls configuration is incorrect.
CONFIGURATION FAULT
10.2.3 Status indication S2 - warnings
Faults are indicated within the status indication S2:
WARNING IND. S2
NO WARNINGS
59
