AUMA SG 05.1 User Manual

Within actuator controls: pollution degree 2
Outside actuator controls (in closed condition): pollution degree 4
Pollution degree
Standard: Two-component iron-mica coatingFinish coating
Standard: AUMA silver-grey (similar to RAL 7037)Colour
Refer to name plate
Standard:
●
–25 °C to +70 °C
Options:
●
–40 °C to +70 °C
●
–50 °C to +70 °C
Low temperature versions incl. heating system for connection to external power supply 230
V AC or 115 V AC.
Ambient temperature
Open-close duty (operating cycles OPEN - CLOSE - OPEN):
SG 05.1 – SG 07.1: 20,000
SG 10.1: SG 15,000
SG 12.1: 10, 000
Modulating duty:
1)
SGR 05.1 – SGR 12.1: 2.5 million modulating steps
Lifetime
Refer to separate technical dataWeight
The lifetime depends on the load and the number of starts. A high starting frequency will rarely improve the modulating accuracy.To
reach the longest possible maintenance and fault-free operating time, the number of starts per hour chosen should be as low as permis-
sible for the process
1)
12.5 Accessories
AUMATIC mounted separately from the actuator, including plug/socket connector. Connecting
cables on request. Recommended for high ambient temperatures, difficult access, or in case
of heavy vibration during service
Wall bracket
1)
The control voltage of the reversing contactors is interrupted by operating the EMERGENCY
STOP button.
EMERGENCY STOP button
2)
COM-AC. An interface cable is required for the standard infra-red programming interface.Programming software for PC
Cable distance between actuator and AUMATIC max. 100 m. Requires separate data cable for MWG. If actuator and AUMATIC are
separated at a later date, the max. cable length is 10 m.
1)
Only in combination with reversing contactors and AUMATIC AC 01.1 in enclosure protection IP 67 or IP 682)
12.6 Further information
●
Electromagnetic Compatibility (EMC): (2004/108/EC)
●
Low Voltage Directive: (2006/95/EC)
●
Machinery Directive: (2006/42/EC)
EU Directives
69
SG 05.1 – SG 12.1/SGR 05.1 – SGR 12.1 Control unit: electronic (MWG)
AC 01.1 Non-Intrusive Modbus RTU Technical data
