Standard:
Reversing contactors (mechanically and electrically interlocked) for motor power up to power
class A1
Options:
●
Thyristor unit for mains voltage up to 500 V AC (recommended for modulating actuators)
for AUMA power class B1
Switchgear
1)
Via fieldbus interfaceControl
Via fieldbus interfaceOutput signals
Standard:
Modbus RTU interface without additional inputs
Options:
Additional inputs.The following version are available:
●
4 free 24 V DC inputs (current consumption: approx. ca. 5 mA/input) and 2 free 0/4 – 20
mA inputs. Signal transmission is made via fieldbus interface.
●
24 V DC control inputs OPEN – CLOSE – EMERGENY, or alternatively OPEN – STOP
– CLOSE (current consumption: approx. 5 mA/input). Selection of control mode via 24
V DC BUS/REMOTE input
●
24 V DC control inputs OPEN - CLOSE (current consumption: approx. 5 mA/input) and
0/4 – 20 mA input for position setpoint (positioner). Selection of control mode via 24 V
DC inputs BUS/REMOTE and MODE
●
24 V DC (115 V AC as option) control inputs OPEN - STOP - CLOSE - EMERGENCY
(current consumption: approx. 5mA/input) and 0/4 – 20 mA input for position setpoint
(positioner)
-
Selection of control mode via 24 V DC (optional 115 V AC) BUS/REMOTE and MODE
inputs
-
Status signals via 6 programmable output contacts, position feedback signal 0/4 –
20 mA
Fieldbus interface
Standard:
Auxiliary voltage 24 V DC, max. 100 mA for supply of the control inputs, galvanically isolated
from internal voltage supply
Option:
Auxiliary voltage 115 V AC, max. 30 mA to supply the control inputs
2)
, galvanically isolated
from internal voltage supply
Voltage output
Additional redundant Modbus RTU interfaceComponent redundancy (option)
AUMATIC is equipped with an additional redundant Modbus interface to form a redundant
loop when combined with the SIMA Master Station
●
Max. number of actuators equipped with AUMATIC actuator controls per redundant loop:
247 units. Max. possible cable length between the actuators equipped with AUMATIC
actuator controls without external repeater: 1,200 m
●
Max. possible total cable length per redundant loop: approx. 290 km
Redundancy in loop structure
(option)
Standard:
●
Selector switch LOCAL - OFF - REMOTE (lockable in all three positions)
●
Push buttons OPEN - STOP - CLOSE - RESET
●
5 indication lights:
-
End position CLOSED and running indication CLOSE (yellow), torque fault CLOSE
(red), motor protection tripped (red), torque fault OPEN (red), end position and running
indication OPEN (green)
●
LC display, illuminated
●
Programming interface (infra-red)
Options:
●
Bluetooth programming interface is equipped with a class II Bluetooth chip with a range
of up to 10 m.The interface supports the Bluetooth protocol SPP (Serial Port Profile).
●
Enabling the local controls using selector switch LOCAL - OFF - REMOTE via fieldbus
This way, actuator operation via push buttons of local controls can be either enabled or
disabled.
●
Special colours for the 5 indication lights:
-
End position CLOSED (green), torque fault CLOSE (blue), torque fault OPEN (yellow),
motor protection tripped (white), end position OPEN
●
Protection cover, lockable
●
Protection cover with indicator glass, lockable
Local controls
65
SG 05.1 – SG 12.1/SGR 05.1 – SGR 12.1 Control unit: electronic (MWG)
AC 01.1 Non-Intrusive Modbus RTU Technical data
