30
 Name Column – this column displays the parameter names.
a) Check Box – tap the check box at the left side of the parameter name to
make selection of an item. Tap the check box again to deselect.
b) Drop-down Button – tap the drop-down button at the right side of the
parameter name to open a submenu, which provides optional modes by
which to display the data.
 Value Column – displays the values of the parameter items.
 Range Column – displays the minimum and the maximum limit value.
 Unit Column – displays the unit for the parameter values.
 To change the Unit mode, tap the Setting button on the top toolbar and
select a required mode. See Unit on page 73.
3. Display Mode
There are four types of display modes available for data viewing, allowing you
to view various types of parameters in the most suitable way for better data
check-ups.
Tap the drop-down button on the right side of the parameter name to open a
submenu. There are 4 buttons to configure the data display mode, plus a Help
button and a Information button on the right, active when additional information
is available for your reference.
Each parameter item displays the selected mode independently.
 Analog Gauge Mode – displays the parameters in form of an analog
meter graph
 Text Mode – the default mode that displays the parameters in texts and
shows in list format.
NOTE
Reading of status parameters, such as a switch reading, which are mostly in
word form, such as ON, OFF, ACTIVE, and ABORT can only be displayed in
Text Mode. Whereas reading of value parameters, such as a sensor reading,
can be displayed in text mode and graph modes.
 Waveform Graph Mode – displays the parameters in waveform graphs.
When displaying this mode, three control buttons will appear on the right side
of the parameter item, allowing you to manipulate the display status.
 Text Button – resumes Text Display Mode.
 Scale Button – changes the scale values, which are displayed below the
waveform graph. There are four scales available: x1, x2, x4 and x8.
 Zoom-in Button – tap once to display the selected data graph in full screen.
