Operator's Handbook, Autroprime Interactive Fire Detection System, 116-P-APRIME-OPERATE/FGB Rev. B, 2009-10-28,
Autronica Fire and Security AS
Page 67
15.4 Show Topology
This menu provides detailed information on the topology of the panel
bus and a selected loop.
From the Service Menu, perform the following:
 Use the arrow down button to scroll downwards to
System Topology, then press Enter.
A list appears, including all loops and the panel bus.
 Use the arrow button to select the panel bus or the loop you
want to view.
 Press the Function button
 Select Show Topology (the uppermost selection), then press
Enter.
The topology details, including Position, Type and Info, will
appear in the display. It is possible to toggle between the tagname
and the production number by using the left and right arrow buttons.
15.5 Show Date and Time
The following is shown:
 current time
 current date
15.6 Software Version Information
The system software version is shown.
15.7 Configuration Version Information
The following is shown:
 site name
 site configuration version
 date
 operator name
 description
 XML format version

