 1 x 5 pin, pitch 2.54mm connector for Inverter
 1 x 2 x 5 pin, pitch 2.54mm connector for Audio
 1 x 3 pin, pitch 2.54mm connector for LVDS PWR selection
 1 x 2 x 12 pin, pitch 2.54mm connector for printer port
 1 x 2 x 5 pin, pitch 2.54mm connector for VGA
 1 x 2 x 5 pin, pitch 2.54mm connector for Keyboard & Mouse
 1 x 1 x 4 pin, pitch 2.00mm connector for Amplifier
Display
Chipset
 Intel NM10 integrated
Resolution
 HDMI:1920 x 1200
 VGA:1920 x 1200
LVDS
 1CH 18/24bits LVDS 1400 x 900
Audio
Chipset
 Realtek ALC661 HD Audio Decoding Controller.
Audio Interface
 Mic-In, Line-In
Audio Amplifier
 Realtek ALC105 Stereo Class-D 3W x 2
Ethernet
Chipset
 2 x Realtek RTL8111E PCI-Express Gigabit Ethernet
Ethernet Interface
 10/100/1000 Gigabit Ethernet
Mechanical &
Environmental
Power
Requirement
 DC in +12V
Power Type
 Single power +12V Power input / ATX mode
ACPI
 Single power ATX Support S0,S1, S3, S4, S5
 ACPI 3.0 Compliant
Operating Temp.
 0°C ~60°C
Storage Temp.
 -40°C ~75°C
Operating
Humidity
 0%~90% relative humidity, non-condensing
Size (L x W)
 6.7" x 6.7" (170mm x 170mm)
Weight
 0.40 kg
Note: The USB keyboard and USB mouse can’t support wake up form S4 mode.
