EMX-CDD User’s Manual
EMX-CDD User’s Manual 9
1.5 Specifications
System
CPU
 Intel® Atom™ processor D2550 Processor
BIOS
 AMI uEFI BIOS, 16Mbit SPI Flash ROM
System Chipset
 Intel® NM10
I/O Chip
 Winbond W83627UHG
System Memory
 1 x 204-pin DDR3 1066/1333 MHz SODIMMs, up to 4GB
Watchdog Timer
 H/W Reset, 1sec. – 65535sec./min
 1sec. or 1min. step
H/W Status
Monitor
 CPU & system temperature monitoring
 Voltages monitoring
Buzzer
 Buzzer onboard
Expansion
 1 x Mini PCI-e (Mini PCI-e and mSATA SSD is Switchable Through Jumper)
I/O
Rear Side External
I/O Connector
 2 x RJ-45
 1 x dual deck USB 2.0 connectors
 1 x VGA
 1 x HDMI
 1 x Mic-In and 1 x Line-out
 1 x DC Jack
Internal I/O
Connector
 Storage:
- 1 x mSATA connector (The mSATA and SATA II is Switchable Through
Jumper)
- 2 x SATA II connector
- 2 x SATA power connectors
 COM:
- COM1~6: support RS-232 connector, Pin 9 without / +5V&+12V supported
 GPIO: 8 bits
 1 x LVDS
 1 x Mini PCI-e slot
 3 x 2 x 5 pin, pitch 2.54mm connector for USB 2.0
 1 x 1 x 4 pin, pitch 2.50mm CPU fan connector with smart fan function
supported
 1 x horizontal type battery connector
 1 x 2 x 8 pin, pitch 2.54mm connector for front panel
 1 x 2 x 2 pin ATX power connector for DC 12V input
 1 x 2 x 20 pin, pitch 1.25mm connector for LVDS
