EMX-CDD User’s Manual
50 EMX-CDD User’s Manual
Port-A:LFP Driven by Int-Display Port encoder
from Port-A. eDP Port-D:LFP Driven by
Int-DisplayPort encoder from Port-D(through
PCH).
Fixed Graphics Memory
Size
128 MB[Default]
256 MB
Configure Fixed Graphics Memory Size.
3.6.3.2 South Bridge
Item
Options
Description
Azalia Controller
Disabled
HD Audio[Default]
Azalia Controller.
Azalia PME Enable
Disabled[Default]
Enabled
Enable or Disable Power Management capability of
Audio Controller.
Azalia Vci Enable
Disabled
Enabled[Default]
Azalia supports 1 extended VC, which, when
enabled, overrides ICH VCp settings.
USB Function
Disabled
1 USB Ports
2 USB Ports
3 USB Ports
4 USB Ports
5 USB Ports
6 USB Ports
7 USB Ports
8 USB Ports[Default]
Enable/Disable USB Function.
Onboard LAN 1/2 Conroller
Disabled
Enabled
Auto[Default]
Enable/Disable Onboard Lan Controller.
PCIE1X Configuration
PCI Express Root Port 1 Settings.
