EMX-CDD User’s Manual
16 EMX-CDD User’s Manual
Connectors
Label
Function
Note
FPANEL1
Front Panel Switches
2 x 8 header, pitch 2.54 mm
MPCIE_WIFI_SATA
PCIE signal selector
HDMI1
HDMI connector
J1
ATX power connector for DC 12V input
JSPK
Speaker connector
1 x 4 wafer, pitch 2.00 mm
J14
DC power-in connector
2 x 2 header, pitch 4.20 mm
JCOM1~6
Serial port 1~6 connector
2 x 5 header, pitch 2.00 mm
GPIO
General Purpose I/O
2 x 6 header, pitch 2.54 mm
JLVDS1
LVDS connector
2 x 20 wafer, pitch 1.25 mm
SATA1~2
Serial ATA connector 1~2
SATA1~2_PWR
SATA Power connector 1~2
1 x 4 header, pitch 2.54 mm
F_MIC1
Mic-in audio jack
3.5mm phone jack
F_OUT1
Line-out audio jack
3.5mm phone jack
RJ45LAN1~2
LAN port 1~2
F_USB1~3
USB connector 1~3
2 x 5 header, pitch 2.54 mm
USB1
USB connector
SFAN1
System Fan connector
1 x 3 wafer, pitch 2.54 mm
CFAN1
CPU Fan connector
1 x 4 wafer, pitch 2.50 mm
JLPT
Printer
2 x 12 header, pitch 2.54 mm
DIMM1
DDR3 SODIMM socket
VGA1
VGA connector
JVGA
VGA connector
2 x 5 header, pitch 2.54 mm
JINVERT1
Inverter connector
1 x 5 header, pitch 2.54 mm
KM1
Keyboard & Mouse connector
2 x 5 header, pitch 2.54 mm
F_AUDIO1
Front Panel Audio Connection Header
2 x 5 header, pitch 2.54 mm
JSPIDF1
Sony/Philips Digital Interface
1 x 5 header, pitch 2.54 mm
IRDA
IRDA connector (not supported)
1 x 5 header, pitch 2.00 mm
