EMX-CDD User’s Manual
46 EMX-CDD User’s Manual
3.6.2.7.7 Parallel Port Configuration
Item
Option
Description
Parallel Port
Disabled
Enabled[Default]
Enable or Disable Parallel Port
(LPT/LPTE).
Change Settings
Auto[Default]
IO=378h; IRQ=5;
IO=378h; IRQ=5,6,7,11,12;
None use
None use
Select an optimal setting for
Super IO device.
Device Mode
STD Printer Mode[Default]
SPP Mode
EPP -1.9 and SPP Mode
EPP -1.7 and SPP Mode
ECP Mode
ECP and EPP 1.9 Mode
ECP and EPP 1.7 Mode
Change the Serial Port mode.
Select <High Speed> or <Normal
mode> mode.
