120 AVANIT SXHD
1. Select Satellite to select the satellite that should be used as reference for
USALS control of the antenna.
2. Select Transponder to select the transponder that should be decisive for
the antenna position (usually the transponder that is used to send your
preferred channel).
3. Align your motor antenna so that signal strength and signal quality (are
displayed at the lower screen edge) reach maximum values.
4. Press EXIT to return to the submenu Antenna Setup.
In the submenu Antenna Setup, select the item Limit Setup and press OK
to open the window Limit Setup. Proceed as described above.
6.2.4 Single Satellite
Here you can scan individual satellites for receivable channels.
At Satellite, select the satellite for which the scan should be performed.
Also here, options are limited to the satellites that are
marked in the Satellite List as such satellites from which
you want to receive channels.
Select Only FTA
30
to determine if scan should be made only for FTA chan-
nels or for all channels.
At Scan Channel, select if you want to perform scan only for TV channels,
only for radio channels or for TV + radio channels.
At Network Search, select if you want to search for an individual channel
(No) or all channels of a channel network (Yes), e.g. PRO7, SAT1, KABEL1, SIXX.
The item Network Search will only be active after selecting the scan mode
Preset Scan (i.e. Standard Scan).
At Scan Mode, select the scan mode:
− Preset Scan (Standard Scan): In such mode, only the frequencies in-
cluded in the TP list are regarded.
− Auto Scan (Blind Scan): Here, all frequencies are scanned, whether they
are included in the TP list or not.
30
FTA = Free To Air = unencrypted channels
