Figure 2: EDM window
Navigation tree
The navigation tree displays available command topics as folders in a tree.
To open a folder or sub-folder, you can click the arrowhead to the left of the folder or double-
click the folder to display the available commands tabs.
To close a folder, click the arrowhead once.
To access a command tab, click the selection in the navigation tree.
Navigation tree toolbar
You can use the toolbar above the navigation tree to perform common functions more easily.
Figure 3: Toolbar
The following is a description of the toolbar button functions:
Button Description
Switch Summary — you can use the Switch Summary toolbar button to open
or reopen the switch summary tab.
Refresh Status — in addition to the existing refresh methods you can use the
Refresh Status toolbar button to refresh the device status
Enterprise Device Manager concepts
Fundamentals December 2011 29
