Page #40 background imageLoading...
Page #40 background image
Field Description
Port
Edit Displays the Edit port dialog box and tabs.
Graph Displays the graph port dialog box and
tabs.
Enable Enables the port administratively.
Disable Shuts down the port administratively.
Opening folders and tabs
The following section describes how to navigate around Enterprise Device Manager (EDM)
and open folders and tabs.
Navigating around EDM
About this task
Use the following procedure to navigate around EDM.
Procedure
1. In the navigation pane, click the arrowhead located to the left of a folder to display
the sub-level folders in the tree.
2. If there is a sub-folder, double-click the folder or click the arrowhead to open the
sub-folder.
3. The primary tabs appear under the folders and sub-folders. Click a tab to open it in
the work area.
Undocking tabs
About this task
To improve certain types of configuration, you can view more than one tab at a time. To view
more than one tab, you use the undock function to activate a previously-opened tab from the
menu bar.
Important:
When you undock a tab to make changes, then return to another open tab, in order to see
the effects of the changes you must click the Refresh button on the tool bar.
User interface fundamentals
40 Fundamentals December 2011
Comments? infodev@avaya.com

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Avaya 4550T-PWR+ and is the answer not in the manual?

Avaya 4550T-PWR+ Specifications

General IconGeneral
Model4550T-PWR+
Device TypeSwitch
Power Over Ethernet (PoE)Yes
PoE StandardIEEE 802.3af, IEEE 802.3at
PoE Budget740W
Switching Capacity176 Gbps
Forwarding Rate131 Mpps
RAM512 MB
Power DeviceInternal power supply
Voltage Required100-240 VAC
Operating Temperature0 °C to 45 °C
AC Input Voltage100-240 VAC
AC Input Frequency50/60 Hz
Enclosure TypeRack-mountable
MAC Address Table Size32K entries
Routing ProtocolOSPF
Remote Management ProtocolSNMP
FeaturesFlow control, VLAN support, Quality of Service (QoS), IGMP snooping, DHCP support, IPv6 support
Compliant StandardsIEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Storage Temperature-40°C to 70°C
Humidity10% to 90% (non-condensing)
ManagementWeb-based management, CLI, SNMP
Ports48 x 10/100/1000Base-T
