Graphing statistics
About this task
You can graph statistics for an entire device, a group of ports, or a single port.
Procedure
1. On the Device Physical View select one of the following:
• a port
• a group of ports
• a device
2. In the navigation tree, double-click Graph.
3. In the Graph tree select one of the following:
• Chassis
• Port
4. On the work area, select a tab.
5. On the tab, select information to graph. To export the information to another
application, on the task bar click Export Data.
6. To create the graph, on the task bar, click a graph type.
Getting EDM online help files for embedded EDM
Because help files are not included with the embedded EDM software files on the switch, you
need to download the help files to a TFTP destination and use ACLI to configure a path from
your switch to the help files. You can also use a USB mass storage device to contain help files
for switches equipped with a USB port.
If you are using COM to manage your switch, help resides with COM and you do not need to
use these procedures.
Downloading help files
About this task
Use the following procedure to download help files.
Enterprise Device Manager procedures
Fundamentals December 2011 51
