Inserting a Fastener into a Garment
1. Place the garment and tag between the reactor plate and the needle guard.
！
！！
！
WARNING
The needles are extremely sharp and may cause serious injury. Keep
hands and personal clothing clear of the needles during operation. Do not
remove the needle guards and do not operate the machine without needle
guards in place. Disconnect power to the machine before replacing needles.
2. Press the foot pedal to actuate the machine.
NOTE
The front door is equipped with an electrical interlock switch that
disables power of motor when the door is opened. The door must
be completely closed to operate the ST9500.
3. Reposition the garment for the next fastener and press the foot pedal.
4. Continue the process until the garment is fully tagged.
