Avery Dennison ST9500 - Default Chapter; Table of Contents

4
Contents
Important Safety Instructions
Chapter 1 Introduction
Chapter 2
Installation
Unpacking the ST9500
TM
……………………………………………… ..............................9
Mounting the ST9500
TM
………………………………………………...............................10
Setting Up the ST9500
TM
………………………………………………. .............................11
Chapter 3 Operation
Operating the Front Panel……………………………………………….............................14
Adjusting Needle Spacing………………………………………………............................18
Double Shot Mode and Single Shot Mode Switch………………..…….............................19
Loading Fasteners………………………………………………………. ...........................20
Adjusting the Fastener Cut ………........................................................................ ..............22
Inserting a Fastener into a Garment ……………………………… ……………………….23
Inspecting the Fastener Cut............................................................ ......................................24
Chapter 4 Theory of Operation
Electric Schematic Block……………………………………………. ...............................26
The ST9500
TM
Cycle …………………………………………………. .............................27
Chapter 5 Parts Replacement
Removing the Enclosure…………………………………………………..........................30
Replacing the Door Needle Guard ………………………………………..........................31
Replacing the Needle Guard………………………………………………........................32
Replacing the Needles……………………………………………………..........................33
Replacing the Ejector Rods………………………………………………..........................34
Replacing the Knife ………………………………………………………........................35
Replacing the Feed Wheel………………………………………………….......................36
Removing the Head Assembly …………………………………………….......................38
Removing the Ejector Slide ………………………………………………........................40
Replacing the Knife Lever …………………………………………………......................41
Replacing and Aligning the Gears …………………………………………......................42
Replacing the Circuit Board ……………………………………………….......................44
Replacing the Capacitor ………………………………………………….. ......................45
Replacing the Motor, Coupling, and Crank Arm Assembly ……………...........................46
