Base Assembly and Body Assembly Spare Parts List:
Item P/N Description Qty.
40 3-05-0001-01 Base 1
41 3-05-0002-01 Arm, Reactor 1
42 3-05-0003-01 Plate, Reactor 1
43 DT0005-001 Pin 5, Locating 2
44 ST0605-001 Machine Buffer 4
45 140001022901 Screw, Hexagon Socket Cup Head, Black 6X25 4
46 140012008601 Washer, Black D6 4
47 140012008101 Lock Washer, Black D6 4
48 140001057701 Screw, Hexagon Socket Cup Head, Black 4X8 2
49 140012008001 Lock Washer, Black D4 2
50 3-05-0004-01 Body 1
51 3-05-0005-01 Stopper, Fabric 1
52 3-05-0006-01 Slider, Fabric Stopper 1
53 DT0005-001 Pin 5, Locating 2
54 140001022901 Screw, Hexagon Socket Cup Head, Black 6X25 4
55 140001003101 Screw, Hexagon Socket Cup Head, Black 6X16 4
56 140012008101 Lock Washer, Black D6 8
57 140012008601 Washer, Black D6 4
58 3-05-0094-01 Thumbscrew 1
59 140012015801 Washer, Black D5 1
60 3-06-0004-01 Assy, Receptacle, Power Cord 1
61 130028003201 Fuse 2
62 3-06-0005-01 Assy, Receptacle, Foot Switch 1
63 3-06-0039-01 Assy, Filter, Power supply 1
64 3-05-0086-01 Bracket, Capacitor 1
65 3-05-0087-01 Cover, Capacitor 1
66 3-06-0040-01 Sub Assy, Circuit, Filter 1
67 140001048702 Screw, Hexagon Socket Cup Head, Black 3X5 4
68 140002011001
Screw, Hexagon Socket Half-
Steel 3X6
4
69 140001001002 Screw, Hexagon Socket Cup Head, Black 3X8 2
70 140012007901 Lock Washer, Black D3 6
71 140012012201 Washer, Black D3 2
72 130903001401 Tie, Fixer 1
73 140001000802 Screw, Hexagon Socket Cup Head, Black 3X6 1
74 130901001401 Tie, Self-Clinching, Nylon 1
75 140002010801
Screw, Half-Rou
nd Crossed Head, Stainless Steel
4X8
1
76 140012012301 Washer, T-Lock, D4 1
