Left and Right Needle Holder Assembly Spare Part List:
Item P/N Description Qty.
210 3-06-0017-01 Assy, Holder, Needle, Left 1
211 3-05-0029-01 Holder, Needle, Left 1
212 3-05-0030-01 Block, Guider, Left 1
213 3-05-0083-01 Screw, Needle Lock 1
214 3-05-0078-01 Plate, Rod Block, Left 1
216 15010-0
TM
Plastic Staple® Fine Fabric Needle 1
216 15011-0
TM
Plastic Staple® Ultra Fine Fabric Needle 1
217 140001048702 Screw, Hexagon Socket Cup Head, Black 3X5 1
218 140001001002 Screw, Hexagon Socket Cup Head, Black 3X8 3
219 140001000302 Screw, Hexagon Socket Cup Head, Black 3X10 2
220 140012007901 Lock Washer, Black D3 6
221 140012012201 Washer, Black D3 2
222 3-06-0018-01 Assy, Holder, Needle, Right 1
223 3-05-0031-01 Holder, Needle, Right 1
224 3-05-0032-01 Block, Guider, Right 1
225 3-05-0083-01 Screw, Needle Lock 1
226 3-05-0080-01 Plate, Rod Block, Right 1
227 15010-0
TM
Plastic Staple® Fine Fabric Needle 1
227 15011-0
TM
Plastic Staple® Ultra Fine Fabric Needle 1
228 140001048702 Screw, Hexagon Socket Cup Head, Black 3X5 1
229 140001001002 Screw, Hexagon Socket Cup Head, Black 3X8 3
230 140001000302 Screw, Hexagon Socket Cup Head, Black 3X10 2
231 140012007901 Lock Washer, Black D3 6
232 140012012201 Washer, Black D3 2
