Installation Manual
P/N 600-00175-000 Rev 04 General Information
- 3 -
2 General Information
This section contains the following information:
● Section 2.1, “Equipment Description” on page 3
● Section 2.2, “MFD Technical Specifications” on page 4
● Section 2.3, “Configuration Options” on page 5
➥ To obtain maximum performance from the MFD, follow the installation instructions carefully.
MFD operating information is contained in the EX500/EX600 Multi-Function Display Pilot's Guide,
which is supplied with the MFD.
➥ Avidyne strongly recommends that you review the Pilot’s Guide before operating the MFD.
The current version of the EX500/EX600 Multi-Function Display Pilot's Guide is available on the web at
www.avidyne.com
.
Note: The conditions and tests required for TSO approval of this article are minimum performance
standards. It is the responsibility of those installing this article either on or within a specific type
or class of aircraft to determine that the aircraft installation conditions are within the TSO
standards. TSO articles must have separate approval for installation in aircraft. The article
may be installed only if the installation is performed in accordance with Part 43 or the
applicable airworthiness requirements.
2.1 Equipment Description
A complete FlightMax EX500/EX600-Series Multi-Function Display system consists of the following
components:
● EX500/EX600 Multi-Function Display (MFD), with standard and optional interfaces.
● System installation kit including MFD tray assembly, and necessary connectors.
● Optional radar interface cables connecting the MFD to the radar receiver/transmitter. These
cables provide a simplified connection to the pre-existing wiring.
● Zip Drive Dataloader (250MB), connector cable, and Zip Disk, or for Release 3 and later, a USB
Flash Memory Drive. For more information about loading data for Release 3 and later, see the
Avidyne Data Update Guide (Document number 600-00148-000).
● User documentation, including the EX500/EX600 MFD Pilot's Guide and Installation Manual
(optional).
!
Warning: AC 20-68B, Recommended Radiation Safety, sets forth recommended
radiation safety precautions to be taken by personnel when operating airborne weather
radar on the ground. Dangers from ground operation of airborne weather radar include
the possibility of human body damage and ignition of combustible material by radiated
energy. The full text of this FAA Advisory Circular may be found on the web at
http://faa.gov/RegulatoryAdvisory/ac_index.htm
.
