Avidyne EX600 Installation Manual

Installation Manual
P/N 600-00175-000 Rev 04 Environmental Qualification Forms
- 83 -
Appendix A: Environmental Qualification Forms
RTCA/DO-160E ENVIRONMENTAL QUALIFICATION FORM
NOMENCLATURE Multi-Function Display
PART NO: 700-00007-(), EX500 & 700-00167-(), EX600
MANUFACTURER: AVIDYNE CORPORATION
ADDRESS: 55 OLD BEDFORD ROAD, LINCOLN, MA 01773
CONDITIONS RTCA/DO-160E
PARAGRAPH
700-00007-()
CONDUCTED TEST
CATEGORY
700-00167-()
CONDUCTED TEST
CATEGORY
TEMPERATURE 4.5 D1 D1
INFLIGHT LOSS OF COOLING 4.5.4 V V
ALTITUDE 4.6.1 D1 D1
DECOMPRESSION 4.6.2 D1 A1
OVERPRESSURE 4.6.3 D1 A1
TEMPERATURE VARIATION 5.0 B B
HUMIDITY 6.0 A A
OPERATIONAL SHOCK 7.2 B B & D
CRASH SAFETY 7.3 B B & D
VIBRATION 8.0 Cat. S Curves M Cat. S Curves M and B
& Cat. U, Curves G
EXPLOSION 9.0 X (Not Tested) X (Not Tested)
WATERPROOFNESS 10.0 X (Not Tested) X (Not Tested)
FLUIDS SUSCEPTIBILITY 11.0 X (Not Tested) X (Not Tested)
SAND AND DUST 12.0 X (Not Tested) X (Not Tested)
FUNGUS 13.0 X (Not Tested) X (Not Tested)
SALT SPRAY 14.0 X (Not Tested) X (Not Tested)
MAGNETIC EFFECT 15.0 Z Z
POWER INPUT 16.0 B B
VOLTAGE SPIKE 17.0 A B
AUDIO FREQUENCY CONDUCTED
SUSCEPTIBILITY
18.0 Z B
INDUCED SIGNAL
SUSCEPTIBILITY
19.0 AC AC
RADIO FREQUENCY
SUSCEPTIBILITY
20.0 D (Conducted), Z
(Radiated)
D
EMISSION OF RADIO
FREQUENCY ENERGY
21.0 M M
LIGHTNING INDUCED TRANSIENT
SUSCEPTIBILITY
22.0 A3E3X (Signal Inputs),
A4E4X (Power Input)
A3E3X (Signal Inputs),
A4E4X (Power Input)
LIGHTNING DIRECT EFFECTS 23.0 X (Not Tested) X (Not Tested)
ICING 24.0 X (Not Tested) X (Not Tested)
ELECTROSTATIC DISCHARGE 25.0 A A
FIRE/FLAMMABILITY 26.0 X (Not Tested) X (Not Tested)
