Installation Manual
P/N 600-00175-000 Rev 04 MFD Feature Setup and Checkout
- 63 -
After restarting the MFD, either of the following messages may appear in the message bar on any
page and in the message list on the Aux or Setup Page.
➥ Make a note of the Receiver ID for the aircraft owner, who will need it to begin Broadcast Datalink
service.
➥ To finish the checkout process, see Section 6.7, “Broadcast Datalink Satellite Reception” on
page 73.
5.10.3 Dimming Bus Setup
On all aircraft, you can configure the LEDs on the bezel to better match the other cockpit instrument
lights on the aircraft dimming bus.
➤ To set the dimming bus:
1. Highlight the Brightest dimming voltage selection. An additional button, Set, appears below the
Save button.
2. Adjust the Airplane dimming bus (usually a knob) to the full bright level. Monitor the dimming bus
voltage on the MFD below the selection boxes. When at full bright, press Set to update the
highlighted field.
3. Highlight the Darkest dimming voltage selection and adjust the airplane dimming bus to a level so
that the other cockpit instruments are at their lowest brightness level.
4. Press Set again to update the Darkest dimming voltage field.
Note: Set the brightness level at the same point where other panel instruments transition from dim
(night) to bright (day) operation.
Dimming Bus Checkout
Restart the MFD. Adjust the aircraft dimming bus and verify that the MFD bezel LEDs match the rest of
the cockpit instrument lamps and lights.
Table 24: Broadcast Datalink Messages
Message Meaning
Broadcast is Operating Normally Verifies that the MFD is communicating with the Broadcast
Datalink Receiver
Broadcast is Not Communicating. (After 5 minutes of no
communication).
The MFD is not communicating with the Broadcast Datalink
Receiver. Check power and signal wiring.
