MFD Technical Specifications P/N 600-00175-000 Rev 04
- 4 -
2.2 MFD Technical Specifications
Table 1: EX500 Technical Specifications
Table 2: EX600 Technical Specifications
Standard Features
Display High Brightness Sunlight Readable Color AMLCD
Diagonal size 5.5 inches
Interfaces RS-232, ARINC 429, ARINC 453, ARINC 407 & TTL
Physical Characteristics
Weight with tray With Quake SC: 7.2 lbs
Without Quake SC: 6.8 lbs
Height 4.35 inches (Face Plate)
Width 6.25 inches (Face Plate)
Depth 12.8 inches (Tray incl. Rear connectors)
Viewing Angle Vertical: +30°, -10°
Horizontal: 60° left and right of center
Operating Limits
Voltage 18-32 VDC, negative ground
Current Maximum: 5 A at 28V
See Appendix A: Environmental Qualification Forms, on page 83 for Environmental Qualification Form
Standard Features
Display High Brightness Sunlight Readable Color Transflective LCD
Diagonal size 5.78 inches
Interfaces RS-232, ARINC 429, ARINC 453, ARINC 407 & TTL
Physical Characteristics
Weight with tray With Fixed Wing Tray: 6.2 lbs
With Helicopter Tray: 9.2 lbs
Height 4.93 inches (Face Plate Front), 4.21 inches (Rear)
Width 6.25 inches (Face Plate)
Depth 12.79 inches (Tray incl. Rear connectors)
Viewing Angle Vertical: +30°, -10°
Horizontal: 60° left and right of center
Operating Limits
Voltage 18-32 VDC, negative ground
Current Maximum: 3 A at 28V
See Appendix A: Environmental Qualification Forms, on page 83 for Environmental Qualification Form
