Installation Manual
Authorized TSOs P/N 600-00175-000 Rev 04
- 84 -
Appendix B: Authorized TSOs
Table 27: Authorized TSOs
Table 28 below lists the TSO deviations that have been granted for the applicable TSOs.
Table 28: TSO Deviations
For some of the functions for which TSO approval has be
en granted, the MFD only provides part of the
functionality covered by the TSO. Table 29 below lists those partial function TSOs along with the
portion of the TSO functionality provided by the MFD.
Table 29: Partial Function TSOs
Applicable TSO Description
TSO-C63c Airborne Weather and Ground Mapping Pulsed Radars
TSO-C110a Airborne Passive Thunderstorm Detection Equipment
TSO-C113 Airborne Multipurpose Electronic Displays
TSO-C118 Traffic Alert and Collision Avoidance System (TCAS) Airborne Equipment, TCAS I
TSO-C147 Traffic Advisory System (TAS) Airborne Equipment
TSO-C157 Aircraft Flight Information Services-Broadcast (FIS-B) Data Link Systems and Equipment
TSO-C165 Electronic Map Display Equipment for Graphical Depiction of Aircraft Position
TSO Description of Deviation
TSO-C157 The EX500/EX600 MFD provides a simple scaling and smoothing mechanism to overlay
NEXRAD on a variable range moving map in a distinctive, easy to interpret format. At large
map ranges, small areas of high-intensity NEXRAD may not be displayed.
On the map page, the MFD is capable of displaying a number of weather
data products, including NEXRAD, graphical METARs, SIGMET and
AIRMET areas, and various forecast products. Of these, only NEXRAD
displays product age.
TSO-C165 Curved flight plans are not displayed if connected to a GNS-400/500 navigator via RS232.
TSO Function Performed by MFD
TSO-C63c Display function only
TSO-C110a Display functions only
TSO-C118 Display functions only
TSO-C147 Display functions only
TSO-C157 Airborne display functions only
