Avidyne EX600 Installation Manual

Installation Manual
Configuration Options P/N 600-00175-000 Rev 04
- 8 -
35 SYNCHRO Y IN 74 SYNCHRO REF HI
36 GND 75 ARINC 453 RX1 A RADAR
37 GND 76 RESERVED
38 RESERVED 77 RESERVED
39 RESERVED 78 ARINC 453 RX1 B RADAR
Table 5: ARINC Port Pinout Cross-Reference
ARINC 429 Ports ARINC 453 Ports
Port Signal Suggested
Pin
Your Setup Port Signal Suggested
Pin
Your Setup
1 TX A 43 1 TX A N/A
TX B 63 TX B N/A
RX A 5 RX A 75
RX B 25 RX B 78
2 TX A 6 2 TX A N/A
TX B 26 TX B N/A
RX A 45 RX A 56
RX B 65 RX B 59
3TX A46 3TX A55
TX B 66 TX B 58
RX A 8
RX B 28
4TX A9
TX B 29
RX A 48
RX B 68
Table 4: Main Connector (P2) Pin Assignments (Continued)
Pin Function Suggested Your
Setup
Pin Function Suggested Your
Setup
