Avidyne EX600 Installation Manual

Installation Manual
P/N 600-00175-000 Rev 04 Unpacking the MFD
- 11 -
3 Unpacking the MFD
The shipping carton for the FlightMax EX500, Avidyne P/N 850-00010-XXX contains one of the
following configurations:
The shipping carton for the EX600, Avidyne P/N 850-00208-XXX contains one of the following
configurations:
Note: When unpacking or servicing the EX500/EX600, do not lay the MFD down on its face. This
can break the knobs and render the MFD unusable.
Table 7: EX500 Part Numbers
Part Number
Qty Black w/
Quake SC
Grey no
Quake SC
Black, no
Quake SC
Grey w/
Quake SC
Description
700-00007-() 1 -001 -701 -801 -901 EX500, no RADAR
-002 -702 -802 -902 EX500, RDR1100/1200 (RT-
131A*, RT-1201A1
*
)
*. With DA-1203A antenna
-003 -703 -803 -903 EX500, RDR1300 (RT-1301A1
∗
)
-004 -704 -804 -904 EX500, RDR 130/150 (RT-131A)
RDR 160 (ART-161A
†
)
†. With one of the following antennas: AT-133A, DA-144A, AT-133A inverted, DA-144A inverted
-005 -705 -805 -905 EX500, RDS8X, RDR2XXX
(RS-18X, RS-8XX, ART-2XXX)
-006 -706 -806 -906 EX500, WXR270/270A
(WXT-250A, WXT-250B)
600-00078-000
600-00078-001
1 FlightMax EX500-Series MFD Pilot's Guide.- Pre-Release 4, or
EX500/EX600 MFD Pilot's Guide.- Release 4 or Later
Table 8: EX600 Part Numbers
Part Number Qty Black Grey Description
700-00167-() 1 -001 -011 EX600, no RADAR
-002 -012 EX600, RDR1100/1200 (RT-
131A*, RT-1201A1
*
)
*. With DA-1203A antenna
-003 -013 EX600, RDR1300 (RT-1301A1
∗
)
-004 -014 EX600, RDR 130/150 (RT-131A)
RDR 160 (ART-161A
†
)
†. With one of the following antennas: AT-133A, DA-144A, AT-133A inverted, DA-
144A inverted
-005 -015 EX600, RDS8X, RDR2XXX
(RS-18X, RS-8XX, ART-2XXX)
-006 -016 EX600, WXR270/270A
(WXT-250A, WXT-250B)
600-00078-001 1 EX500/EX600 MFD Pilot's Guide.- Release 4 or Later
