Installation Manual
Configuration Options P/N 600-00175-000 Rev 04
- 12 -
Locate the labels on the bottom of the MFD. Verify that the MFD includes the ordered feature option
set marked on the label.
The shipping carton of the FlightMax EX500 Installation Kit, Avidyne P/N 850-00011-000 contains the
following components:
The shipping carton of the EX600 Fixed-Wing Installation Kit, Avidyne P/N 800-00039-000 contains
the following components:
The shipping carton of the EX600 Helicopter Installation Kit, Avidyne P/N 800-00039-001 contains the
following components:
➥ Ensure that all the parts were received and sustained no shipping damage.
If damage occurs during shipping, the damaged shipping carton and packing material will help
substantiate your claim to the shipping company. Retain the original shipping carton and packing
material in case you need to ship the unit for service.
Part Number Qty Description
700-00009-000 1 EX500 Tray Assembly
030-00181-000 1 Connector, D-Sub 78F, w/ backshell & Pins
150-00100-000 8 Screw, 4-40 x ¼ Flat, SS, 100 Degree
600-00004-000 1 EX500 Installation Documentation CD
Part Number Qty Description
700-00168-000 1 EX600 Fixed Wing Tray Assembly
030-00181-000 1 Connector, D-Sub 78F, w/ backshell & Pins
150-00100-000 8 Screw, 4-40 x ¼ Flat, SS, 100 Degree
600-00011-000 1 EX600 Installation Documentation CD
Part Number Qty Description
700-00168-001 1 EX600 Helicopter Tray Assembly
030-00181-000 1 Connector, D-Sub 78F, w/ backshell & Pins
150-00100-000 8 Screw, 4-40 x ¼ Flat, SS, 100 Degree
600-00011-000 1 EX600 Installation Documentation CD
!
Do not open the MFD cover in any manner and do not remove the internal
CompactFlash memory card, unless the operation is being conducted by authorized
personnel using an approved Avidyne Service Bulletin. Otherwise, the CompactFlash
memory or MFD may be damaged.
