Installation Manual
P/N 600-00175-000 Rev 04 General Information
- 5 -
2.3 Configuration Options
To support the many sensor types encountered in the typical aircraft installation, the installer must
configure the EX500/EX600 for the sensor type and select the correct port configuration. Table 3 lists
sensor options and their associated port configurations. This data may be used when executing
Maintenance Mode sensor setup utilities. Port selection must match the aircraft wiring. Default port
assignments must match the wiring diagrams shown in Appendix F: EX500/EX600 General Wiring, on
page 95 through Appendix J.8 WXR250/270/300 RADAR w/Adaptor Cable Wiring, on page 107.
When the MFD is used in conjunction with a digital radar system, ARINC 429 TX port 3 and ARINC
453 RX port 1 are default settings, which are not selectable via the procedures contained in this
document. Table 4, “Main Connector (P2) Pin Assignments,” on page 7 provides a cross reference
between port assignments and functional use.
The selected ports are displayed on the Port Info Page, described in Section 6.1, “System Info Pages”
on page 69
Table 3: Sensor Port Configuration Options
Sensor Type Sensor Option Port Type Default
Port
System Type Port
Config.
GPS/FMS GAMA 429 Format ARINC 429 1 Garmin GPS 155XL,
GNC 300XL
Speed: Low
1 Garmin GPS 400/500 Speed: Low
1 Garmin GNC 420 Speed: Low
1 Garmin GNS 430/530 (including
430W/530W)
(GAMA 429 Graphics w/INT)
Speed: Low
1 Bendix/King GNS-XLS Speed: Low
1 Bendix/King KLN-90B Speed: High
1 Universal UNS-1B Speed: High
King/Aviation Format RS-232 1 Bendix/King GNS-XLS Baud: 9600
Bendix/King KLN-89B Baud: 9600
Bendix/King KLN-90B Baud: 9600
1 Bendix/King KLN-94 Baud: 9600
1 Garmin GNS 430/530 Baud: 9600
1 Garmin GNS 480 Baud: 9600
1 Trimble 2000, 2101 Baud: 9600
1 UPSAT – all GPS units Baud: 9600
Northstar Format RS-232 1 Northstar M3 Baud: 9600
NMEA 0183 Format RS-232 1 Garmin 150/250 Baud: 4800
