A320 PersonAl Mixer User GUide
64-Channel Systems
The diagram below shows a 64-input system. The A320 Personal Mixers use inputs 1-32 only; the A360
Personal Mixer can use any slot in the network when configured in its Custom mode.
D800
AN-16/i v.2
AN-16/i v.2
AN-16/i v.2
AN-16/i v.2
e
to/from Personal Mixers
Load
Power
Sync
12345678
D800
I II I II I II I II I III II I III II
D800
e
to/from Personal Mixers
Load
Power
Sync
12345678
D800
I II I II I II I II I III II I III II
Channels 1-16Channels 1-16
Channels 17-32Channels 17-32
Channels 33-48Channels 33-48
Channels 49-64Channels 49-64
Select A360 mix channels
from all 64 network slots
(
CUSTOM mode)
Select A360 mix channels
from all 64 network slots
(CUSTOM mode)
A320 Personal Mixers use
network slots 1-32
A320 Personal Mixers use
network slots 1-32
to additional
Personal Mixers
to additional
Personal Mixers
A 64-input system using two A-Net Distributors is shown.
Legacy Products
A-16II or A-16R Personal Mixers may be used in a Pro16e-based system, but note that they can only access
the first 16 network slots.
