4. Move the tab of the Upper Pickup Roller outward to remove it from the
scanner.
5. Reinsert the new ADF Pick Rollers by first insert the right end of the Upper
Pick Roller to its slot.
6. Move the tab of the Upper Pickup Roller inward as shown.
Pickup Roller
Upper Pickup
Roller
