ELtron protocol
Transmission parameters: 8 bits, 1 stop bit, no parity, baud rate 9600bps,
 After using key in scale:
 ScaleLabel printer : set of instruction in EPL-2 language that initialize
label printing:
US
-
Steering instruction
FR"0001"
-
Label number define instruction
?
-
Instruction that starts list of variable signs
mm:gg
-
5 signs: minutes:hour
rrrr.mm.dd
-
10 signs: year.month.day
masa
-
10 signs: scale indication+ mass unit
P1
-
Steering instruction
Attention:
1. Except variable signs constant signs also can be inscribed for example factory
name, product name and so on.
2. In standard one label pattern is possible to prinout (number 0001). Using
bigger amount of patterns (other label numbers) is possible thanks to LAbEL
special function.
3. To achieve label printout, label printer must have inscribed label pattern (label
pattern is created on computer and using computer it is saved to label printer
memory). Label pattern is designed by ZEBRA DESIGNER program which is
supplied together with label printer.
Scales parameters and transmission protocol must corespond to label printer
type.
