AXIS P5512 PTZ Dome Network Camera
Events
Parameter
Object Size
History
Sensitivity
Description
Object size rela tive to window
size.
Object memory length.
Difference in luminance
between background and
object.
High level (100%)
Only very large objects trigger
motion detection.
An object that appears in
the window triggers motion
detection for a long time
before it is considered as
non-moving.
Ordinary colo red objects on
ordinary backgrounds trigger
motion detection.
Medium level (50%)
A large difference in luminance
is required to trigger mot ion
detection.
Low level (0%)
Even very small objects trigger
motion detection.
An object that appears in
the window triggers motion
detection only for a very short
time before it is considered as
non-moving.
Only very bright objects on
a dark background trigger
motion detection.
Recommended values
5–15% 60–90% 75–95%
Default values
15% 90% 90%
Tips:
• To trigger on small objects or movements, use several small motion detection windows rather than one large window
and select a low object size.
• To avoid triggering on small objects, select a high object size.
• If no objects should appear in the Include Window, select a high history level. This w ill cause motion detection to trigger as
long as the object is present in the window .
• To only detect flashing light, select a low sensitivity. In other cases high sensitivity is recommended.
Audio detection
The Axis product can be confi gured to generate an alarm when audio rises above, falls below or passes the audio alarm level.The
alarm level can be set in the range 0–100 where 0 is the most sensitive and 100 the least sensitive.
1. Go to Events > A udio Detection.
2. Set the audio alarm level and click Save.
3. Go to Events > Event Types andsetupatriggeredevent,seeSet up a triggered event, on page 28.
Note
A multi-connector cable (available from Axis) is required when connecting external audio equipment to the Axis product.
See Multi-Connector Cable (sold separately), o n page 45.
Port Status
The list on the Events > Port Status page shows the status of the product’s input and output ports. Inputs and outputs are configured
from the System Options > Ports & Devices page which requires administrator rights.
Note
A multi- connector cable (available from Axis) is required when connecting I/O devices to the Axis product. See
Multi-Connector Cable (sold sep arately), on page 45.
31
