Axis P5512 PTZ User Manual

AXIS P5512 PTZ Dome Network Camera
Hardware overview
Hardware overview
1
2
3
4
5
6
7
8
9
10
11
1.
Unit holders (3)
2.
Camera base lid
3.
Part number (P/N) & Serial number (S/N). The serial number may be required during the installation.
4.
Camera base lid screws (4)
5.
Hook for safety wire
6.
Cable tracks
7.
Network connector
8.
Rubber gasket
9.
Multi connector
10.
Top cover screws (4)
11.
Top cover
1
2
3
4
5
6
7
8
9
1.
Ceiling ring
2.
Top cover
3.
Dome cover
4.
Dome ring
5.
Dome ring screws (8)
6.
Status indicator LED
7.
Control button
8.
SDHC card slot
9.
Restart button
4
