7) Mounting procedure
The procedure for connecting pneumatic piping to operate the device is shown below.
Step Work
1
Connect the joint for piping to the connection port using seal
tape.
Handling Precautions:
- Use seal tape as the seal material. Avoid using solid
or liquid seal material if possible.
- Do not let the seal tape get in the piping.
- If you do use a liquid seal, make sure that no drops
of the seal material get in the piping.
2
Connect the supply and output pipes to each joint in
consideration of the arrangement of the piping.
Handling Precautions:
- For the double-acting actuator, the connection
between output air connection ports OUT1 and
OUT2 and the actuator is determined by the
valve operation. Check the valve operation before
connecting pipes.
- Sufficiently flush piping before connection to prevent
burrs on the piping or other foreign objects from
getting in the piping.
- Keep the output air piping as short as possible.
3 After all piping is complete, make sure that air does not leak.
