3-4
Setup modeSetup mode
Enter the password if a
password has been set.
If you use another host or
communicator for communication
during setup, this screen is displayed
and the setup mode cannot be started.
There is no loop that
goes back to AS
U.
Hold down
Monitor modeMonitor mode
Status monitorStatus monitor
Details monitorDetails monitor
Normal monitor
Normal monitor
When the alarm is
activated in the nomal
monitor, the alarm
messages are displayed.
The codes are the same
as those of 5-2.
As for the display variation, refer to Appendix A.
Figure 3-2
To Next Page
