To reduce risk of electric shock which could cause personal injury, follow all safety
notices in this documentation.
This symbol warns the user of a potential shock hazard where hazardous live voltages
may be accessible.
• If the equipment is used in a manner not specified by the manufacturer, the protection
provided by the equipment must be impaired.
• Do not replace any component (or part) not explicitly specified as replaceable by your
supplier.
• All wiring must be in accordance with local norms and carried out by authorized and
experienced personnel.
• A switch in the main supply is required near the equipment.
• Main power supply wiring requires a (T) 200mA, 250V fuse(s) (IEC 127).
EQUIPMENT RATINGS
Supply voltages: 100 to 240V (operating power supply voltage 85 to 264Vac)
Frequency: 50/60Hz
Power consumption: 12VA maximum
EQUIPMENT CONDITIONS
Do not operate the instrument in the presence of flammable liquids or vapors.
Operation of any electrical instrument in such an environment constitutes a safety hazard.
Temperature: 0 to 50˚C
Humidity: 10 to 90%RH (no condensation)
Vibration: 2m/s
2
(10 to 60Hz)
Over-voltage category: Category II (IEC60364-4-443, IEC60664-1)
Pollution degree: Pollution degree 2
EQUIPMENT INST
ALLATION
The controller must be mounted into a panel to limit operator access to the rear terminal.
Specifications of common mode voltage: The common mode voltages of all I/O except for main
supply and relay outputs are less than 30Vr.m.s, 42.4V peak and 60Vdc.
ST
ANDARDS COMPLIANCE
EN61010-1, EN61326-1
SAFETY REQUIREMENTS
