Azbil SDC15 User Manual

7-5
Chapter 7. LIST OF SIMPLE CONFIGURATION DISPLAY ITEMS
7 - 3 List of Setup Setting Displays
Display Item Contents Initial value Notes
PV input range type
When the PV input type is thermocouple: 1 For details, refer to the PV input
1 to 6, 9 to 11, 13 to 21, 24, 25 range table (on page 5-3).
When the PV input type is RTD: 41
41 to 46, 51 to 54, 63, 64, 67, 68
When the PV input type is DC 88
current/voltage: 84, 86 to 90
Temperature unit 0: Centigrade (˚C) 0 Displayed when the PV input type is
1: Fahrenheit (˚F) thermocouple or RTD.
Decimal point position 0: No decimal point 0 Displayed when the PV input type
1 to 3: Digits after decimal point (selected by the model number) is
DC current/voltage, or when a
thermocouple or RTD range with a
decimal point is selected.
PV input range low
When the PV input type is thermocouple —
limit
or RTD, the setting is disabled and the
input range low limit selected with the
PV input type (C01) is displayed.
When the PV input type is DC current/ 0
voltage, a value ranging from -1999
to +9999 is set.
PV input range high
When the PV input type is thermocouple —
limit
or RTD, the setting is disabled and the
input range high limit selected with the
PV input type (C01) is displayed.
When the PV input type is DC current/ 1000
voltage, a value ranging from -1999
to +9999 is set.
Control action 0: Reverse action (Heat control) 0 Displayed when the heat/cool control
(Direct/Reverse) 1: Direct action (Cool control) selection is not used (C26=0).
Heat/Cool control 0: Disabled. 0 Displayed when two control output
selection 1: Enabled. points or event output is provided.
Heat/Cool control -100.0 to +100.0% 0.0 Displayed when using the heat/cool
deadband control selection (C26=0).
LSP system group 1 to 4 1
CT1 operation type 0: Heater burnout detection 0 Displayed when the optional model
1: Current value measurement
has two current transformer input points.
CT1 output 0: Control output 1 0 Displayed when the optional model
1: Control output 2 has two current transformer input
2: Event output 1 points and the CT1 operation type is
3: Event output 2 set at "heater burnout detection"
4: Event output 3 (C36 = 0).
CT1 measurement 30 to 300 ms. 30 Displayed when the optional model
wait time has two current transformer input
points and the CT1 operation type is
set at "heater burnout detection"
(C36=0).
CT2 operation type 0: Heater burnout detection 0
Displayed when the optional model has
1: Current value measurement two current transformer input points.
CT2 output 0: Control output 1 0 Displayed when the optional model
1: Control output 2 has two current transformer input
2: Event output 1 points and the CT2 operation type is
3: Event output 2 set at "heater burnout detection"
4: Event output 3 (C39 = 0).
