5 - 3 Internal Event
In "Simple configuration", the internal event must be set when using the event output, an additional function of the model.
In "Simple configuration", the operation type, Direct/Reverse, standby, MV in READY mode, main setting, and sub-setting
of the internal event can be set. With the default settings before shipment, the internal event process has been connected
directly to the event output. Therefore, the optional event output of the model is operated only with the internal event setting.
The following describes the event operation.
Note
For details about U (unit), refer to the attached glossary.
5-13
Chapter 5. SETTINGS BEFORE STARTING OPERATION
Operation type Set value Direct action Reverse action
of operation
type
No event 0 Always OFF Always OFF
PV high limit 1
PV low limit 2
PV high/low limit 3
Deviation high 4
limit
Deviation low limit 5
Deviation high/ 6
low limit
Deviation high limit 7 Same as the direct action of the deviation high limit. Same as the reverse action of the deviation high limit.
(Final SP reference) (The difference is that the SP ramp does not use (The difference is that the SP ramp does not use
the current SP, but it uses the final SP.) the current SP, but it uses the final SP.)
Deviation low limit 8 Same as the direct action of the deviation low limit. Same as the direct action of the deviation low limit.
(Final SP reference) (The difference is that the SP ramp does not use (The difference is that the SP ramp does not use
the current SP, but it uses the final SP.) the current SP, but it uses the final SP.)
Deviation high/ 9
Same as the direct action of the deviation high/low limit. Same as the reverse action of the deviation high/low limit.
low limit (The difference is that the SP ramp does not use (The difference is that the SP ramp does not use
(Final SP reference) the current SP, but it uses the final SP.) the current SP, but it uses the final SP.)
SP high limit 10
ONHYS
ON
HYS
Main setting
Main setting
PV
PV
Main setting
PV
Main setting
PV
ONHYS
ON
HYS
Main setting
Sub-setting
PV
SP
ON
HYS
ONHYS
ONHYS
HYS
Main setting
Sub-setting
PV
SP
ONHYS
ON
HYS
Main setting
Main setting
SP
SP
Main setting Sub-setting Main setting Sub-setting
PV
PV
ON
HYS
ONHYS
ONHYS
HYS
ONHYS
ON
HYS
SP + Main setting SP + Main setting
PV
PV
SP + Main setting
PV
SP + Main setting
PV
ONHYS
ON
HYS
● shows that the ON/OFF is changed at this value.
❍ shows that the ON/OFF is changed at a point that
"1U" is added to this value.
● shows that the ON/OFF is changed at this value.
❍ shows that the ON/OFF is changed at a point that
"1U" is added to this value.
