Azbil SDC46 User Manual

2-2
Chapter 2. PARA BANK SETTINGS
Display Loop number
(auxiliary display)
Item PID
value
Settings and descriptions Initial
value
User
setting
Remarks
P-04 L. 1.
Proportional band 4 Same as PID1 5.0 Same as PID1
I -04 L. 1.
Integral time 4 120
d-04 L. 1.
Derivative time 4 30
OL-04 L. 1.
Output low limit 4 0.0
OH-04 L. 1.
Output high limit 4 100.0
rE-04 L. 1.
Manual reset 4 50.0
P-04C L. 1.
Proportional band for cool side 4 5.0
I -04C L. 1.
Integral time for cool side 4 120
d-04C L. 1.
Derivative time for cool side 4 30
OL.04C L. 1.
Output low limit for cool side 4 0.0
OH.04C L. 1.
Output high limit for cool side 4 100.0
P-05 L. 1.
Proportional band 5 Same as PID1 5.0 Same as PID1
I -05 L. 1.
Integral time 5 120
d-05 L. 1.
Derivative time 5 30
OL-05 L. 1.
Output low limit 5 0.0
OH-05 L. 1.
Output high limit 5 100.0
rE-05 L. 1.
Manual reset 5 50.0
P-05C L. 1.
Proportional band for cool side 5 5.0
I -05C L. 1.
Integral time for cool side 5 120
d-05C L. 1.
Derivative time for cool side 5 30
OL.05C L. 1.
Output low limit for cool side 5 0.0
OH.05C L. 1.
Output high limit for cool side 5 100.0
P-06 L. 1.
Proportional band 6 Same as PID1 5.0 Same as PID1
I -06 L. 1.
Integral time 6 120
d-06 L. 1.
Derivative time 6 30
OL-06 L. 1.
Output low limit 6 0.0
OH-06 L. 1.
Output high limit 6 100.0
rE-06 L. 1.
Manual reset 6 50.0
P-06C L. 1.
Proportional band for cool side 6 5.0
I -06C L. 1.
Integral time for cool side 6 120
d-06C L. 1.
Derivative time for cool side 6 30
OL.06C L. 1.
Output low limit for cool side 6 0.0
OH.06C L. 1.
Output high limit for cool side 6 100.0
P-07 L. 1.
Proportional band 7 Same as PID1 5.0 Same as PID1
I -07 L. 1.
Integral time 7 120
d-07 L. 1.
Derivative time 7 30
OL-07 L. 1.
Output low limit 7 0.0
OH-07 L. 1.
Output high limit 7 100.0
rE-07 L. 1.
Manual reset 7 50.0
P-07C L. 1.
Proportional band for cool side 7 5.0
I -07C L. 1.
Integral time for cool side 7 120
d-07C L. 1.
Derivative time for cool side 7 30
OL.07C L. 1.
Output low limit for cool side 7 0.0
OH.07C L. 1.
Output high limit for cool side 7 100.0
P-08 L. 1.
Proportional band 8 Same as PID1 5.0 Same as PID1
I -08 L. 1.
Integral time 8 120
d-08 L. 1.
Derivative time 8 30
OL-08 L. 1.
Output low limit 8 0.0
OH-08 L. 1.
Output high limit 8 100.0
rE-08 L. 1.
Manual reset 8 50.0
P-08C L. 1.
Proportional band for cool side 8 5.0
I -08C L. 1.
Integral time for cool side 8 120
d-08C L. 1.
Derivative time for cool side 8 30
OL.08C L. 1.
Output low limit for cool side 8 0.0
OH.08C L. 1.
Output high limit for cool side 8 100.0
P-09 L. 1.
Proportional band 9 Same as PID1 5.0 Same as PID1
I -09 L. 1.
Integral time 9 120
d-09 L. 1.
Derivative time 9 30
OL-09 L. 1.
Output low limit 9 0.0
OH-09 L. 1.
Output high limit 9 100.0
rE-09 L. 1.
Manual reset 9 50.0
P-09C L. 1.
Proportional band for cool side 9 5.0
I -09C L. 1.
Integral time for cool side 9 120
d-09C L. 1.
Derivative time for cool side 9 30
OL.09C L. 1.
Output low limit for cool side 9 0.0
OH.09C L. 1.
Output high limit for cool side 9 100.0
